Marker R Sensor

LED indoor wall-mounted die cast aluminium step light

Marker series is a simple and modular design step, corridor and room luminaires and consists of a special optical design for no glare and highly uniform illumination.
Available in round and square shapes with Motion sensor optional.

Enquire about this product
Specifications
  • Materials: Asymmetric optics
  • Finishes: Silver / White / Black
  • LED Power: 4W
  • Lumens: 80lm
  • CCT: 3000K/4000K/6000k
  • IP Rating: IP20
  • CRI: >80
  • SDCM: <3
  • Lifetime: >50,000h L80
  • Warranty: 5 Years
Features and Details
  • Minimal design with no visible screw design
  • Special optical design for high levels of visual comfort
  • Long range with optimum illumination
  • An integral non-dimmable led driver
  • Motion sensor optional
  • The mounting box for installation into concrete is included
  • 5-year warranty
Downloads
IES Files Installation instructions Product images Specifications Download all
Configure
SKU Finish CCT CRI Lumen IP Rating
MR-B4803NM Black (RAL 9005)3000K>8080lmIP20
MR-B4804NM Black (RAL 9005)4000K>8080lmIP20
MR-B4806NM Black (RAL 9005)6000K>8080lmIP20
MR-S4803NM Silver (RAL 9006)3000K>8080lmIP20
MR-S4804NM Silver (RAL 9006)4000K>8080lmIP20
MR-S4806NM Silver (RAL 9006)6000K>8080lmIP20
MR-W4803NM White (RAL 9016)3000K>8080lmIP20
MR-W4804NM White (RAL 9016)4000K>8080lmIP20
MR-W4806NM White (RAL 9016)6000K>8080lmIP20
